| Attribute |
Details |
| Type |
Stud Bolts (Threaded Rods, Double-Ended Studs, Anchor Studs) |
| Material |
- Carbon Steel (ASTM A193 Grade B7, ISO 898-1 Grade 10.9)
- Stainless Steel (304/316, A193 Grade B8/B8M)
- Alloy Steel (ASTM A320 Grade L7 for Low-Temp Use)
- Titanium (Grade 2/5) |
| Finish |
- Zinc Plated (RoHS/REACH Compliant)
- Hot-Dip Galvanized (ASTM A153)
- PTFE Coated (for Chemical Resistance)
- Passivated (Stainless Steel) |
| Thread Type |
- Metric (M6-M100, ISO 965-1)
- Imperial (1/4"-4", UNC/UNF/UNJ)
- API Threads (for Oil & Gas Pipelines)
- Custom Threads (Buttress, Acme) |
| Design |
- Full Thread (ISO 4027)
- Half Thread (ISO 8677)
- Tap Bolt Style (One End Threaded, One End Plain for Anchoring) |
| Length |
- Standard: 50mm–3000mm (Metric); 2"–120" (Imperial)
- Custom Lengths: Up to 6000mm (20ft) for Special Projects |
| Strength Grade |
- Carbon Steel: 8.8, 10.9, 12.9
- Stainless Steel: A2-70, A4-80
- Alloy Steel: ASTM A193 B7 (Tensile Strength: 830 MPa) |
| Standards Compliance |
- ISO 8677 (Stud Bolts)
- ASTM A193/A194 (Pressure Vessel Bolts)
- ASME B1.1 (Unified Thread Standard)
- EN 1090 (Structural Engineering, upon request) |
| Corrosion Resistance |
- Salt Spray Test: 500–1000 Hours (Zinc Coatings)
- Corrosion Resistance: 316SS for Marine/Chemical Environments |
| Packaging |
- Bulk: Bundled in Polypropylene Straps with Labeled Cartons
- Palletized (Securely Wrapped for Long-Distance Shipping)
- Custom: Protective Caps for Thread Ends (MOQ 1000+) |
| Certifications |
- API 20E (Oil & Gas), ASME BPVC (Pressure Vessels)
- RoHS, REACH, CE
- Material Test Reports (MTR) with Ultrasonic Testing (UT) Results |
| Applications |
- Pipeline Flanges (Oil & Gas, Chemical Plants)
- Pressure Vessels, Heat Exchangers
- Structural Steel Connections, Machinery Assembly
- Solar Panel Mounting, Wind Turbine Foundations |
| Minimum Order Quantity (MOQ) |
500 Pieces (Standard Sizes); 1000 Pieces (Custom Threads/Materials) |
| Delivery Time |
10–25 Days (Standard); 30–45 Days (Special Materials/Custom Lengths) |
| Customization |
- Thread Length Ratio (e.g., 2D/3D Threaded Ends)
- Shoulder Studs (Unthreaded Mid-Segment for Alignment)
- Thread Locking Coatings (e.g., Loctite) |
- Industry Compliance: Meets API, ASME, and ISO standards for critical applications like oil & gas pipelines and pressure vessels, ensuring regulatory approval globally.
- Material Versatility: High-temperature (ASTM A193 B8) and low-temperature (A320 L7) grades available for extreme environments.
- Bulk Efficiency: Competitive pricing for large orders, with palletized shipping and custom packaging to reduce logistics costs.
- Precision Engineering: Full/half-thread options and custom shoulder designs improve assembly accuracy in machinery and structural projects.
- Corrosion Solutions: Marine-grade stainless steel and PTFE coatings address harsh environmental challenges in offshore and chemical industries.
