Heavy-Duty Shield Anchors are robust mechanical fasteners designed to secure extremely heavy loads to concrete, masonry, or stone substrates. Unlike standard anchors, they feature a unique shield (expansion sleeve) that flares outward when tightened, creating a powerful grip for high-tensile and shear loads. Manufactured from carbon steel (hot-dip galvanized), stainless steel (316), or alloy steel (Grade B7), they are ideal for industrial, infrastructure, and seismic-resistant projects.
- Material:
- Carbon Steel: Grade 8.8/10.9 (HDG-coated, ASTM A307/A153).
- Stainless Steel: 316 (A4, passivated for marine/chemical environments).
- Alloy Steel: ASTM A193 Grade B7 (heat-treated for high-temperature resistance).
- Size Range:
- Diameter: 1/2"–4" (imperial) / M12–M100 (metric).
- Length: 3"–36" (75–900 mm, including embedment depth).
- Design Features:
- Shield Sleeve: Split, flanged design for maximum expansion and load distribution.
- Threaded Rod: Full-length threads for adjustable nut positioning.
- Head Style: Hex head or weldable base for permanent installations.
- Load Capacity:
- Tensile Strength: 5,000–50,000 lbs (2,268–22,680 kg) per anchor.
- Shear Strength: 4,000–40,000 lbs (1,814–18,144 kg) per anchor (tested to ASTM E488).
- Standard Carbon Steel HDG (1/2"–2"): 1,000 pieces (in-stock sizes).
- Stainless Steel 316 (M24–M60): 500 pieces (custom orders).
- Oversized Alloy Steel (3"–4"): 200 pieces (project-specific manufacturing).
Factory Advantages: ISO 17025-certified testing labs, ASME BPVC Section VIII compliance for pressure vessels, and support for custom shield geometries or seismic-resistant designs with lead times of 20–45 days.
- Industrial Machinery: Securing presses, turbines, and generators in manufacturing plants.
- Infrastructure: Anchoring bridge bearings, stadium seating, and heavy-duty rail systems.
- Energy Sector: Mounting wind turbine bases, solar tracker foundations, and nuclear facility components.
- Seismic Zones: High-durability anchors compliant with AISC 341 and UBC 97 for earthquake-resistant structures.
- Expansion Technology: Shield design ensures uniform load distribution, reducing stress on concrete.
- Corrosion Resistance:
- HDG carbon steel: 1,500+ hours salt spray (ASTM B117).
- 316 stainless steel: 2,500+ hours salt spray for offshore/chemical plants.
- Temperature Stability: Maintains strength from -60°C to +500°C (alloy steel Grade B7).
- Code Compliance: Meets ICC-ES AC308, Eurocode 2, and Chinese GB 50017 standards.
- Material Upgrades: 2507 duplex stainless steel for ultra-corrosive environments.
- Coatings: Zinc-aluminum (ZAL) for 3,000+ hours salt spray or PTFE for low-friction applications.
- Special Features:
- Pre-galvanized threads to prevent seizure.
- Load-rated color coding (e.g., red for 20,000 lbs, blue for 30,000 lbs).
- Rigorous Testing: Each batch undergoes proof load testing and ultrasonic thickness measurement for coating integrity.
- Design Support: Free finite element analysis (FEA) for complex load scenarios.
- Sustainability: Recycled steel content up to 80% and low-VOC coating processes.
Contact Us
Request a quote for heavy-duty shield anchors engineered for your project’s unique demands! Factory-direct supply ensures compliance with global standards and reliable performance in the most challenging environments.
