Anchor Bolts are critical components in structural engineering, designed to transfer loads from superstructures to concrete foundations. Their robust design—featuring a threaded end for nut engagement and a non-threaded anchored end (J-shaped, L-shaped, or with a forged head)—ensures secure embedment and resistance to pulling or shear forces. Widely used in commercial construction, industrial machinery mounting, and infrastructure projects, these bolts are engineered for durability, corrosion resistance, and compliance with global building codes.
| Attribute |
Details |
| Type |
- J-Bolts
- L-Bolts
- Headed Anchor Bolts (Hex Head, Mushroom Head)
- Threaded Rod Anchors |
| Material |
- Carbon Steel: Grade 5 (ASTM A307), Grade 8.8 (ISO 898-1)
- Stainless Steel: 304/316 (A2/A4)
- Alloy Steel: Grade B7 (ASTM A193) for high-temperature applications |
| Coating |
- Hot-Dip Galvanized (HDG, ASTM A153): Salt spray resistance ≥1,000 hours
- Epoxy-Coated: UV and chemical resistance
- Zinc-Plated: Basic corrosion protection |
| Design Features |
- Anchored End: J/L shape for pull-out resistance; headed design for shear strength.
- Threaded End: Full or partial threads for nut and washer attachment.
- Diameter: M12–M100 (metric) / 1/2"–4" (imperial).
- Embedment Length: 150–3,000 mm (customizable for concrete depth requirements). |
| Standards Compliance |
- ASTM F1554 (Structural Anchor Bolts)
- EN 1992-4 (Eurocode 2: Concrete Structures)
- GB 50017 (Chinese Steel Structure Design Code) |
| Applications |
- Structural steel column bases
- Bridge abutments and piers
- Heavy machinery (presses, generators)
- Wind turbine foundations
- Retaining walls and seismic-resistant structures |
| Performance Ratings |
- Tensile Strength: 600–1,200 MPa (depending on grade)
- Shear Strength: 400–800 MPa
- Corrosion Resistance: Meets ASTM B117 salt spray standards |
| Packaging |
- Bulk: Palletized in steel drums or wooden crates
- Custom: Anti-rust oil coating + moisture-proof wrapping for overseas shipping |
| Certifications |
- CE, UL, CSA
- ISO 9001:2015
- Material Test Certificates (MTC) with tensile test reports |
| Minimum Order Quantity (MOQ) |
500 Pieces (standard sizes); 1,000 Pieces (stainless steel/custom designs) |
| Delivery Time |
15–30 Days (standard); 35–50 Days (large-diameter or special coatings) |
| Customization |
- Non-standard lengths and diameters
- High-strength coatings (e.g., Dacromet for offshore use)
- Pre-assembled with nuts, washers, and anchor plates |
- Structural Integrity: Engineered to withstand high tensile and shear loads, ensuring stability in seismic and wind-prone regions.
- Corrosion Resistance: Hot-dip galvanized and stainless steel options meet coastal, industrial, and harsh environment requirements.
- Code Compliance: Approved for use in North American, European, and Asian construction projects (e.g., IBC, Eurocode, GB standards).
- Factory Direct Pricing: Competitive costs for bulk orders, with fast turnaround on standard J/L bolts and custom-headed designs.
- Engineering Support: Free technical drawings and load calculation assistance for complex projects.
- Quality Assurance: Manufactured in ISO-certified facilities with 100% dimensional and torque testing.
- Versatility: Suitable for concrete, masonry, and composite foundations, with options for both static and dynamic loads.
- Global Logistics: Flexible shipping via sea, air, or land, with door-to-door delivery available for international clients.
- Commercial Buildings: Securing steel beams to concrete slabs in high-rise construction.
- Industrial Plants: Mounting large boilers, tanks, and production lines.
- Renewable Energy: Anchoring wind turbine bases and solar panel structures.
Contact us today for detailed specifications, pricing, or samples. Our team specializes in custom anchor solutions for unique project requirements.
